PCB Routing And Fabrication Machine

Watch a 4 spindle Excellon Mark 5 DR (Driller/Router) routing a stack of printed circuit boards. See how the automated process works.

Circuit boards are typically manufactured in a step and repeat layup, and held in place on the machine with tooling pins through the circuit board and into the soft tooling plates. Stack height varies depending on board thickness and material type.

Cutter bits for cutting PCBs are typically solid tungsten carbide, with a diamond cut geometry design. Table feed presented in the video is typical for a .093 inch diameter bit.

For more information related to service, maintenance, repairs, and preventative maintenance go to Excellon Machines. For informative articles related to drilling and routing, take a look at the postings published at Probe Industries Blog. Read the article: Understanding TIR and Measuring Spindle Runout. To get help with all your drilling and routing equipment service needs contact Probe Industries today.
